Double-sided LED neon Flex

Double-Sided Silicone LED neon 16x12mm

Cross section size： 16x12mm(WXH)
Power/m： 10W (max.15w/m is available )
Input Voltage： DC24V
CRI： 90
Bending direction： Horizontal bending
IP grade： IP67
INQUIRY

Double-Sided Silicone LED neon 16x12mm

*IP67 FLEX LEDNEON ,unique two-sided luminous structure design, can be used as a variety of

scene atmosphere lighting.Cross section size 16mm x 12mm(W x H) ,which is horizontal bending

with min.bending diameter of 200mm

*Colors option: 2400k,2700K,3000K,4000k,6500K,Red,Green,Blue,Yellow,Pink , Orange,CCT,RGB

*It is IP67 protected, silicone material,UV resistant, solvents resistant and saltwater resistant.

*Dot free will bring the most excellent performance for indoor & outdoor applications.

Dimension

Technical Data

Model	CCT/Color	Input voltage	Power/m	CRI	Lumen(LM/M)	Max.length (single feed)	Unit Cut
MGS-SV1612DN-2400K	2300-2500K	DC24V	10W	90+	520lm	13m	50mm
MGS-SV1612DN-2700K	2600-2800K	DC24V	15W	90+	520lm	13m	50mm
MGS-SV1612DN-3000K	2900-3100K	DC24V	10W	90+	550lm	13m	50mm
MGS-SV1612DN-4000K	3800-4300K	DC24V	10W	90+	600lm	13m	50mm
MGS-SV1612DN-6000K	5900-6400K	DC24V	10W	/	550lm	13m	50mm
MGS-SV1612DN-R	RED 620-625nm	DC24V	10W	/	210lm	17m	50mm
MGS-SV1612DN-G	GREEN 515-525nm	DC24V	10W	/	550lm	13m	50mm
MGS-SV1612DN-B	Blue 460-465nm	DC24V	10W	/	110lm	13m	50mm
MGS-SV1612DN-Y	Yellow 585-595nm	DC24V	10W	/	210lm	17m	50mm
MGS-SV1612DN-PINK	PINK	DC24V	10W	/	480lm	13m	50mm
MGS-SV1612DN-O	Orange 600-610nm	DC24V	10W	/	200lm	17m	50mm
MGS-SV1612DN--CCT	2700+6000K	DC24V	10W	90+	580lm	5m	62.5mm
MGS-SV1612DN--RGB	RGB	DC24V	10W	/	220lm	5m	50mm

Note: -The max. length is based on Constant Current DC24V CC LED Strip,if constant voltage DC24V CV LED Strip. Max.length is 5meters power from single feed
